Artec 1 Ton APEX Front SuperDuty Swap Kit 2005+ (Wrangler JK, JL & Gladiator JT 2007+)

• ATENT PENDING APEX Truss peaked top design provides more rigidity than a flat top truss design
• CNC Precision Laser cut in-house from 1/4" and 3/16" mild steel for a lightweight yet strong solution...starting at only 30 lbs total
• CNC Precision Bent in-house for a great fitment. Literally drop the truss in place on the axle and it's ready to weld. No puzzle piece assembling*
• Designed used 3D models directly from Ford and Jeep for not only an amazing fit but clearances with surrounding components
• 70% less welding needed than previous truss designs means less warping, faster turnaround, and lower costs
• All long seams are bent so you don't need to spend time welding them together
• Dimpled holes provide not only weight reduction but rigidity and strength
• Contours both the cast steel differential and can be welded with normal MIG welder and moderate pre-heating and post-heating
• OEM location Upper Control Arms mount to an ultra high clearance Differential Bridge that hugs the shape of the casting (bushing or Johnny Joint option).
• Truss extends under coil buckets all the way to inner C for end-to-end rigidity
• Multi-piece truss design means smaller packaging and less shipping costs along with easy installation
• Using a 1 ton axle will support larger tires and less chance of breakage in extreme conditions
• Coil brackets and bump stop pads are combined to form an axle tube truss and allows for easy installment of other brackets
• Includes all the brackets necessary for a complete axle swap including upper and lower control arm mounts, shock mounts, anti-sway bar mounts, trackbar mount, bumpstop pads and coil spring mounts.
• Heavy duty Trackbar bracket can slide to multiple positions for steering geometry fine tuning
• Shock brackets have been moved up and out (compared JK OEM position) for a slightly higher clearance for  lower control arms and frame
• Overall low profile design means your axle is stronger, sleeker, easier to fit into any vehicle, and less likely to interfere with vehicle components.****

Notes:
** This kit requires general welding and fabrication skills. Welding should only be done by a competent welder who understand different materials. Some welding of cast and mild steel will be used. Artec Industries and Offroad Elements Inc. imply no guarantees or warranties and are not liable for improper installation.
*** Some grinding and fitment may be required when installing this kit. Every axle varies slightly and some fabrication may be required. Will require brake line relocation to fit.
**** In rare and extreme cases, the truss may come into contact with oil pan. Prior to operating the vehicle, remove the coil springs, cycle the suspension including full compression of both sides simultaneously and add bumpstop extensions to prevent damage to oil pan.

IMPORTANT KIT NOTES:
- The front 60 that works with this kit is from Ford SuperDuty F-250 and F-350 trucks from model years 2005+ (coil sping). This truss is not intended for older axles due to differential offsets
- Trimming of the factory differential casting will be necessary (see instructions). Other fabrication and modifications may be needed due to variances in lift kits and other factors.
- Due to the larger casting on the 60 differential, the Lower Control Arm (LCA) brackets are wider than factory location (41.5" Center to Center). Modifications to your Lower Control Arms will likely be necessary. If you have adjustable arms with flexible style joints (heims, Johnny Joints, etc), modifications may not be necessary. Upper Control Arm (UCA) brackets are also slightly higher than factory so adjustable arms may be necessary. The shock mounts are also slightly higher (1.25") than stock to clear the lower control arms.
- This kit does not include any parts for ABS sensors. It is only a bracket kit. Hooking up and configuring these sensors is the end users responsibility
- 60 axles DO NOT MATCH the factory JK 5 lug wheel bolt pattern. New wheels will need to be purchased to do this swap. Brake and Steering components NOT INCLUDED in this product, but will be available soon.
- This will likely require bumpstop extensions and a new trackbar since the steering is different on this axle from factory axle. The trackbar bracket is higher than stock location to allow proper steering geometry.

Fits:
Jeep Wrangler JK 2 Door (2007-2018)
Jeep Wrangler JK 4 Door Unlimited (2007-2018)
Jeep Wrangler JL 2 Door (2018+)
Jeep Wrangler JL 4 Door Unlimited (2018+)
Jeep Gladiator JT (2020+)
